China Volumetric Infusion Pump, Poweam Portable Infusion Pump on Sale

Product Description

Volumetric Infusion Pump, Poweam Portable Infusion Pump on sale (CI-3000)

3.5" TFT color and touch screen for easy view and convenient operation
Horizontal flat and compact design with anti-corrosion PBT material
Flexible stack by innovative integrated rail design
Exact delivery rate in increments of 0.01ml/h
Online titration function to change flow rate during operation
Dynamic Pressure Surveillance(DPS)
Recognize syringe brands and size from 5ml to 60ml automatically
Multiple infusion modes:Only rate, V-T, R-T, Dose rate, Loading dose, Trapezia, Sequence and Interrupt Model
Dural CPU design assures the safety of system
Flow compensation to avoid error caused by pipeline fatigue
Anti-bolus function for the safety of patients
Up to 2000 event logs
Anti-free flow to prevent liquids free flow when door keeps open
Daytime mode and night time mode interchange automatically
Both audible and visible alarm, and 9 level alarm sound adjustable
Infusion pump Voltage:100 to 240 VAC
Frequency:50Hz / 60Hz
Battery type:Rechargeable lithium-ion battery 10-15V 2.5A
Charging Time:≤4 hours
Infusion pump Working Time:≥6 hours
Screen:3.5" TFT color and touch screen
Screen brightness:9 grade adjustable, manufacturer default is the 5th grade

Power Supply:
Voltage:			100 to 240 VAC			Frequency:			50Hz / 60Hz
Rated power:			35VA
Rechargeable Battery:
Battery type			Rechargeable lithium-ion battery 10-15V 2.5A
Charging Time			≤4 hours			Working Time			≥6 hours
Operating Environment:
Temperature:			+5~+40ºC			Relative humidity:			10%~90%
Atmospheric pressure:			70~106kPa
Shipment and Storage Environment:
Temperature:			-30~+70ºC			Relative humidity				10%~90%
Atmospheric pressure:			22~106khPa.
Dimension and Weight:
Size(LWH/mm):			24017580			Net Weight :				1.80kg
Packing Size(LWH/mm):			414238154			Gross Weight:				2.80 kg
Safety Requirement
Reference Standard:			EN 60601-1:2006; EN 60601-1-2:2007;EN 60601-1-6:2010;EN 60601-1-8:2007;BS EN 62304-2006;IEC60601-2-24:2012 ;			Waterproof grade:				IPX3
Accuracy:
Infusion rate:		(0.1~2000) ml/h			Rate increment:		(0.1-99.99)ml/h,0.01ml/h;(100.0-999.9)ml/h,0.1ml/h;(1000-2000)ml/h,1ml/h;
VTBI		(0.1-9999)ml			VTBI Increment:		(0.1-99.99)ml,0.01ml;(100.0-999.9)ml,0.1ml;(1000-9999)ml, 1ml;
Volume accuracy:		± 5%			Mechanical accuracy :		± 0.50%
VTBI time range:		00:00:01-99:59:59(h:M:S)
IV set brand:		Integrated 5 brands, support user extending and calibration
Bolus:
Bolus type:		Automatical Bolus and Manual Bolus
Bolus rate:		(0.1 -2000) ml/h
Automatical Bolus VTBI:		0.1ml~5ml, increment 0.1ml
Keep Vein Open(KVO):
KVO rate range:	(0.1~5.0)ml/h			Increment:				0.1ml
When infusion is completed, it enter KVO mode automatically, KVO can be turned off.
Alarm:
Type of alarm :			Three grade (High, Medium and Low) audible and visible alarm with text prompts;9 levels adjustable alarm beep sound.
Alarm content :			AC power interruption, DC power interruption, Low battery, Depleted battery, Forget reminder, Infusion near end, Infusion complete, Flow rate, Door open, System exception, Upstream Occlusion, Bubble detection alarm
Bubble detection alarm			A single bubble alarm for 25ul, 100ul, 250ul.Cumulated bubble alarm adjustable for 300ul/15min, 500ul/15min
Event Log:
Event log volume :			2000 cases
Event content :			Automatically record alarm information and operation event, including start injecting, injection completed, rate modification, injection volume etc.
Data Communication:
Data transmission interface:			RS232;WIFI for option
Infusion workstation:			It can work together with other pump as part of infusion workstation
Display:
Screen:			3.5" TFT color and touch screen
Screen brightness:			9 grade adjustable, manufacturer default is the 5th grade
Display Content:			Working status, VTBI, VI (Volume Infused), Time remaining, Real-time pressure, Pressure threshold, Alarm content, IV set brand and size, Power state, Date, Time.
Drug Library:
Programmable			It can program drug list according to customer request, and the drug name should be within 32 words.
DERS			Drug Error Revise System for smart and safety
Notice:Drug Library should program by customer according local regulation and clinic demands.
