Product Description

Portable Veterinary Video Endoscope
Model: Gastrix 85V, Gastrix 92V, Colonix 98V, Colonix 130V

Features:
Portable design - 3.5 inches LCD Monitor:
Portable veterinary endoscope adopts the expanded viewing and recording capability. It enables observation without cables or peripherals, providing with a level of mobility that allows it be operated almost anywhere.

Excellent optical system:
High definition image: adopt the 440k pixels, high resolution CCD (color charge-coupled device). It can capture high quality images.
Wider field of view technology can provide excellent and detailed images.
Large range angulations make it easier to observation.
3-100mm depth of view provides precise observation ability for both close and far objects.

Wider instrument channel:
It is easier to operate that a wide range of instruments can be used with the 2.0mm~3.2mm diameter channel.

Specifications for Veterinary Endoscope:

Model	View of Field	Depth of View	Resolution	Working Length	Diameter of Insertion Tube	Diameter of Instrumental Channel	Range of Tip Bending
Gastrix 85V	120°	3-100mm	440K pixels	1500mm	8.5mm	2.0mm	210°(U),90°(D), 100°(R),100°(L)
Gastrix 92V	140°	3-100mm	440K pixels	1500mm	9.2mm	2.8mm	210°(U),90°(D), 100°(R),100°(L)
Colonix 98V	140°	3-100mm	440K pixels	3000mm	9.6mm	2.8mm	210°(U),90°(D), 100°(R),100°(L)
Colonix 130V	140°	3-100mm	440K pixels	3000mm	12.8mm	3.2mm	180°(U),180°(D), 160°(R),160°(L)

Specifications for Imaging Processor:

Model	VIS-1000	VIS-1000R	VIS-1000MR
Difference	Video endoscope compatible	Video/Rigid endoscopy compatible	8 inch LCD standard medical monitor All-in-one solution Rotatable white Balance cap Video/Fiber/Rigid endoscopy compatible
Feature	Integrated unit of Video Processor and Light Source Excellent light output by the use of a powerful LED lamp with daylight spectrum Optimal light yield Integrated insufflation pump Easy replacement of lamp Highest safety standard due to professional CE classification
Outputs	1DVI(DVI-D/A) - digital video output 1USB - digital video output for PC connection 2Video BNC - analog video output 1S-video(Y/C) - analog video output
Specification	Type of lamp LED lamp Nominal power 35W Light intensity 33000lx Color temperature 5500k-7500k Heat insulation filter IR 3 Life time of lamp 20000h

Standard:
Veterinary endoscope, Image processor with light source, 3.5" LCD, Accessories (2×Biopsy Forceps,1×Cytological Brush,1×Cleaning Brush,1×Leakage Tester,1×Manual Syringe,2×Mouth Piece,2×Valve,4×Seal Rings, 1×Metal case)

Optional:
Autoclavable Grasping Forceps, Autoclavable Biopsy Forceps, Autoclavable Grasping Basket, LCD Monitor, Trolley
